Picture of Major Overhaul Kit, John Deere 6068T/H PowerTech Diesel Engine

Major Overhaul Kit, John Deere 6068T/H PowerTech Diesel Engine

Be the first to review this product

Engines equipped w/ a machined split rod. For engine w/ 2 valves per cylinder.Includes:• (6) HCTRE507850 Cylinder Kits• (6) HCTRE65908 Rod Bearings• (6) HCTRE65165 Main Bearings• (1) HCTRE65168 Thrust Bearing• (1) HCTRE501456 Overhaul Gasket Set• (1) HCTRE505515 Front Crank Seal• (6) HCTR114082 Piston Pin Bushings• (1) Rear Crank Seal• (1) HCTR119874 Cam Bushings• (12) HCTR114083 Connecting Rod Bolts• (1) HCTMX506 Grommet Kit• (12) HCTRE31617 Valve Stem SealsThe HCTRE66097 Major Overhaul Kit, John Deere 6068T/H PowerTech Diesel Engine fits equipment brands such as: John Deere

Manufacturer: Hy-Capacity

SKU: HCTRE66097

$1,529.48

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Connecting Rod Marked	R114081
Engine Notes	Turbocharged; 1.625" Piston Pin Diameter
Piston Marked	RE505102; RE55512
Piston Pin Dia.	1.625"
Engine CID	414
Fuel Type	Diesel
Cylinder Count	6
Bore	4.193"
Stroke Length	5.000"
Rod Journal Dimensions	3.0630" - 3.0640"
Main Journal Dimensions	3.1230" - 3.1240"
New/Reman	New
Piston Code	4810; 4820; 4824
Sold As	Each

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Connecting Rod Marked	R114081
Engine Notes	Turbocharged; 1.625" Piston Pin Diameter
Piston Marked	RE505102; RE55512
Piston Pin Dia.	1.625"
Engine CID	414
Fuel Type	Diesel
Cylinder Count	6
Bore	4.193"
Stroke Length	5.000"
Rod Journal Dimensions	3.0630" - 3.0640"
Main Journal Dimensions	3.1230" - 3.1240"
New/Reman	New
Piston Code	4810; 4820; 4824
Sold As	Each

Product tags

RE527324 (1)

Use On Below Models (Click to expand)

John Deere

Combine: 1165 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 1170 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TCQ50 1175 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 1175H 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 1450 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TJ04 2054 6068 Turbo Diesel, Use For Engines With Machined Split Rods 2254 6068 Turbo Diesel, Use For Engines With Machined Split Rods 3518 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HYC53 9400 6068T PowerTech Diesel Engine 9410 6068T PowerTech Diesel Engine 9450 6068T PowerTech Diesel Engine 9470STS 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HCQ04 9540WTS 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HZ060 W210 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TYC52

COMBINE: 1470 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TCQ18

Crawler/Dozer: 750C 6068T PowerTech Diesel Engine 750C II 6068T PowerTech Diesel Engine

CRAWLER/DOZER: 750J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HT058

Engine: PowerTech 6068T/H PowerTech Diesel Engine, Tier 2 & 3

Excavator: 200CLC 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HT053 200LC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 230CLC 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HT054 230LC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 230LCR 6068 Turbo PowerTech Diesel, Use For Engines With Machined Split Rods 270CLC 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HT054 270LC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 690ELC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335

Feller Buncher: 643G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 643H 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 653E 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 653G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 843G 6068T PowerTech Diesel Engine 843H 6068T PowerTech Diesel Engine

Forestry Equipment: 2554 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HT054 330B 4045 Turbo PowerTech Diesel, Use For Engines With Machined Split Rods 335C 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TTJ51 430B 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 435 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 435C 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TTJ51 437C 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TTJ51

Harvester: 6610 6068 Turbo PowerTech Diesel, Use For Engines With Machined Split Rods 7500 6068T PowerTech Diesel Engine

Loader Backhoe: 710D 6068T PowerTech Diesel Engine 710G 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TT057 710J 6068 Turbo PowerTech Diesel, Use For Engines With Machined Split Rods

Motor Grader: 670C 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 670CH 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 672CH 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335

Skidder: 360D 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 360DC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 360DG 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 460D 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 460DC 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 540G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 540G II 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 540G III 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 548G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 548G II 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 548G III 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 640G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 640G II 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 640G III 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 648G 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 648G II 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 648G III 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 740 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TT058

Sprayer: 4700 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 4710 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335

Tool Carrier: TC54H 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 TC62H 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335

Tractor: 1550 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TJ04 6125J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TBM01 6130J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TBM03 6145J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TBM02 6180J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HBM03 6515 6068 PowerTech Diesel, Use For Engines With Machined Split Rods 6605 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 6610 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 6615 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 6620 6068 PowerTech Diesel Engine, Connecting Rod Marked R500335 6715 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 6810 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TL051 6820 6068 PowerTech Diesel Engine, Connecting Rod Marked R500335 6910 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Codes 6068TL052, 6068TL054 6910S 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 6920 6068 PowerTech Diesel Engine, Connecting Rod Marked R500335 6920S 6068 PowerTech Diesel Engine 7185J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HBM04 7205J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HBM04 7210 6068T PowerTech Diesel Engine 7220 6068 PowerTech Diesel, Use For Engines With Machined Split Rods 7320 6068 PowerTech Diesel, Use For Engines With Machined Split Rods 7405 6068T PowerTech Diesel Engine 7410 6068T PowerTech Diesel Engine 7420 6068T PowerTech Diesel Engine 7425 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TP057 7505 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TCQ03 7510 6068T PowerTech Diesel Engine 7515 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TBM02 7520 6068T PowerTech Diesel Engine 7525 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TP057 7610 6068T PowerTech Diesel Engine 7715 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HCQ01 7810 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TRW73 7815 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HRW63 SE6520 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HL270 SE6620 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Codes 6068HL272, 6068TL072 SE6920 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068TL074

TRACTOR: 6165J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HBM02

Wheel Loader: 544H 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 544HLL 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335 624H 6068 PowerTech Diesel Engine, Connecting Rod Marked R500335 624HLL 6068 PowerTech Diesel Engine, Connecting Rod Marked R500335

WHEEL LOADER: 544J 6068 Turbo PowerTech Tier 1 Diesel Engine, w/ Engine Code 6068HDW56

Windrower: 4990 6068 Turbo PowerTech Diesel, Use For Engines With Machined Split Rods 4995 6068T PowerTech Diesel Engine, Connecting Rod Marked R500335
