Upper Parallel Arm, Short

Exact Align Pro parallel arm row kit to fit John Deere XP, ME5, ME+ planter row units with the long 23-inch parallel arms. The Exact Align Pro arm kits is provided as a complete solution which includes two upper arms, one lower arm with pre-installed 204 series ball bearings and associated hardware. This kit is for use with row units attaching to wide mounting plates on the planter toolbar frame meaning the arms fit inside of the mounting bracket. Upper arms are made from precision laser-cut steel while the lower arm is made from super strong ductile cast which is approximately 40% heavier than the OEM part. Even brand-new OEM parallel arm and bushings allow for excessive play which only gets worse over time and use of the planter. The Exact Align Pro system is designed to eliminate unwanted play by ensuring positive connection points by employing sealed ball bearings for very long life. Exact Align Pro parallel arms are meant to be the last set of parallel arms you will ever buy as if any bearings were to fail, they can easily be replaced. Made in the USA.

Exact Align Pro parallel arm row kit to fit John Deere XP, ME5, ME+ planter row units with the short 15-3/4-inch parallel arms. The Exact Align Pro arm kits is provided as a complete solution which includes two upper arms, one lower arm with pre-installed 204 series ball bearings and associated hardware. This kit is for use with row units attaching to wide mounting plates on the planter toolbar frame meaning the arms fit inside of the mounting bracket. Upper arms are made from precision laser-cut steel while the lower arm is made from super strong ductile cast which is nearly 2x heavier than the OEM part. Even brand-new OEM parallel arm and bushings allow for excessive play which only gets worse over time and use of the planter. The Exact Align Pro system is designed to eliminate unwanted play by ensuring positive connection points by employing sealed ball bearings for very long life. Exact Align Pro parallel arms are meant to be the last set of parallel arms you will ever buy as if any bearings were to fail, they can easily be replaced. Made in the USA.

Update your John Deere MaxEmerge®XP, XP Pro, MaxEmerge 5, ExactEmerge planter gauge wheel arms to Exact Align Pro to ensure exact relationship of the gauge wheel tire to seed disk opener without the need to grease as would be needed with the OEM. Our exclusive design uses 3 rows of sealed ball bearings. Hardware is provided to ensure correct spacing used during the initial setup. Once installed these arms will provide long service life. They fit both the left- and right-hand applications and are reversible. Includes 2 arms and hardware.

Closing Wheel Arm kit that utilizes ball bearings instead of bushings at the pivot points. Cast closing wheel arm with T-handle, pivot stop, spring, hardware. Fits John Deere planter row units MaxEmerge®2, Plus, Pro, XP, XP Pro. John Deere drills 1530, 1535. Includes cast closing wheel arm with T-handle, closing wheel arm stop, tension spring, pivot bushings (wheels not included).

Closing wheel arm with T-handle. Fits John Deere planter row units MaxEmerge®2, Plus, Pro, XP, XP Pro. John Deere drills 1530, 1535. Includes cast closing wheel arm with T-handle, closing wheel arm stop, tension spring, pivot bushings (wheels not included).Great for updating JD 7200 series planters to the newer design.
