Next30 watt PAR-36

40 watt PAR-36

Be the first to review this product

High power 40 watt PAR-36 size replacement LED light for the old style sealed beam halogen light. 4 x 10 watt LED chips. This light will only fit in normal full size housings due to large cooling fins.

SKU: 40w Par-36

Select Beam Type: *

Hi-Lo beam
40° beam
80° Flood Beam

$39.00

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

40 watt PAR-36

Works as a replacement for the halogen sealed beam PAR-36 (4.5" bulb) used on many older tractors,

JD 30, 40 & 50 series IH and many others.

This light has a temperture sensor that will limit the power to the light if the temperture gets too high.

The advertised lumen is when the light is cool enough to opperate at 100%

Note: It is a good practice to drill a few holes on top and bottom of the housing the light is mounted in, this will help the lights cool.

. LED: 40 Watt OSRAM 10W/PC
. Voltage: 10-30 Volt DC
. Lumens: 4000lm Raw, 2800lm Effective
. Power used: 25W / 2A @ 12.5 Volt
. Kelvin: 5500K
. Temperature: -40°F to +140°F
. IP: Waterproof IP68
. Beam: Flood, 40°, or Hi-Lo
. Material: Diecast Aluminum Housing
. Lens: Scratch and UV Resistant Polycarbonate
. Life Time: 50,000 hours
. RFI and EMC filter

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Flood

40 watt PAR-36

Works as a replacement for the halogen sealed beam PAR-36 (4.5" bulb) used on many older tractors,

JD 30, 40 & 50 series IH and many others.

This light has a temperture sensor that will limit the power to the light if the temperture gets too high.

The advertised lumen is when the light is cool enough to opperate at 100%

Note: It is a good practice to drill a few holes on top and bottom of the housing the light is mounted in, this will help the lights cool.

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Flood
